DOME LOADED REGULATOR-44
NU-TECH Dome loaded regulator is a piston sensed, dome loaded and positive biased Where positive bias provide a constant outlet pressure from 50-1500 PSI greater than the reference pressure. Due to the self-vented feature, the outlet pressure can be vented through the regulator allowing downstream regulation even with a decreasing reference pressure.
| Media | All gases and liquids compatible with materials of construction. |
| Max. Inlet Pressure | 5000 psig |
| Outlet Pressure Range | 50 - 1500 psig |
| Design Proof Pressure | 7000 psig |
| Design Burst Pressure | 8000 psig |
| Inlet Size | 1/4", 3/8", 1/2" NPT/BSP. |
| Flow Capacity | Main valve Cv=0.7, Vent Valve Cv=0.35 |
| Materials | Body - SS 304 / SS 316 all adjustable |
| Operating Temperature | -17°C To 170°C |
| Trims | SS |
| Leakage | Bubble Tight CL VI |
