PRESSURE REGULATOR HP-263
NU-TECH Pressure Reducing Valves reduce high stream pressure to constant downstream pressure, outlet pressure across a broad range of flow.
| Media | All gases compatible with materials of construction for other media consultant with factory |
| Inlet Pressure | 6000 psig |
| Outlet Pressure | 4-50, 4-150, 4-250, 4-500 psig |
| Proof Pressure | 8500 psig |
| Burst Pressure | 10000 psig |
| Materials | Body - Stainless steel |
| Flow Capacity | Cv = 0.08 |
| Operating Temperature | -55°C To 75°C |
| Inlet Size | 1/8", 1/4", 3/8", 1/2" NPTF/BSPF |
